S Trymbaka Murthy is a professor in the Department of Mechanical Engineering, Sir M. Visvesvaraya Institute of Technology, Bengaluru. Earlier, he had taught at Siddaganga Institute of Technology, Tumkur. A dedicated teacher with over four decades of teaching experience, Prof. Murthy received his BSc and BE degrees from Yuvaraja’s College and Sri Jayachamarajendra College of Engineering, Mysore, respectively, and his master's degree in machine design from UVCE, Bengaluru.

Preface to the Fourth Edition

Preface to the First Edition

Acknowledgements

Abbreviations, Symbols and Notations

(General)

Abbreviations Recommended by BIS

(IS: 11670-1993)

1.      Introduction

2.      Computer-Aided Drawing

3.      Elements And Principles of Orthographic Projection

4.      FreeHand Sketching

5.      Projections of Points

6.      Projections of Straight Lines

7.      Projections of Plane Surfaces

8.      Projections of Solids

9.      Sections and Section Planes

10.  Development of Lateral Surfaces of Solids

11.  Isometric Projection

Model Question Papers
