TABLE OF CONTENTS
Preface
1. Introduction to Vector Fields
1.1 Introduction
1.2 Basic Definitions
1.3 Vector Addition and Subtraction
1.4 Vector Multiplication
1.4.1 Dot Product
1.4.2 Cross Product
1.5 Triple Products
1.5.1 Scalar Triple Product
1.5.2 Vector Triple Product
1.6 Orthogonal Coordinate System
1.6.1 Cartesian or Rectangular Coordinate System
1.6.2 Circular Cylindrical Coordinate System
1.6.3 Spherical Coordinate System
1.7 Transformation of Vectors
1.8 Differential Elements
1.9 Line, Surface and Volume Integrals
1.10 Gradient, Divergence and Curl of a Vector
1.11 Del Operators
1.12 Useful Theorems
Summary
Review Questions
Problems
Multiple choice Questions
2. Electrostatics
2.1 Introduction to Electrostatic Fields
2.2 Coulomb’s law
2.3 Force in Terms of Rectangular Coordinates
2.4 Force due to N Number of Charges
2.5 Electric Field Intensity (E)
2.6 Charge Distributions
2.7 Electric Field Intensity due to Charge Distributions
2.8 Electric Field due to Infinite Line Charge
2.9 Electric Field due to a Finite Line Charge
2.10 Electric Field Strength due to a Circular Ring of Charge
2.11 Electric Field Strength due to an Infinite Sheet of Charge
2.12 Electric Field Strength due to a Sheet of Circular Disc
2.13 Electric Flux and Flux Density
2.14 Electric Flux Density due to Point Charge Q
2.15 Electric Flux Density due to Charge Distributions
2.16 Gauss’ Law (Integral Form)
2.17 Gauss’ Law in Point Form (Maxwell’s First Law)
2.18 Divergence of Electric Flux Density
2.19 Divergence Theorem of Electric Flux Density
2.20 Electric Flux Density due to an Infinite Line Charge Using Gauss’ Law
2.21 Flux Density due to an Infinite Sheet Charge Using Gauss’ Law
2.22 Flux Density for a Coaxial Cable
2.23 Flux Density for a Spherical Shell of Charge
2.24 Flux Density for a Uniformly Charged Sphere
2.25 Work Done in Moving a Point Charge in an Electrostatic Field
2.26 Electric Potential
2.27 Potential due to a Point Charge
2.28 Potential due to Point Charges
2.29 Potential due to Charge Distribution
2.30 Potential Difference due to an Infinite Line Charge
2.31 Potential due to a Line Charge of Finite Length
2.32 Potential due to a Circular Ring
2.33 Potential Gradient
2.34 Relationship between E and V: Maxwell’s Second Equation
2.35 Potential Function (V )
2.36 Equipotential Surfaces
2.37 Electric Dipole
2.38 Potential due to an Electric Dipole
2.39 Dipole Moment
2.40 Electric Field due to a Dipole
2.41 Torque on an Electric Dipole in an Electric Field
2.42 Energy Stored in an Electrostatic Field
2.43 Energy Stored in Terms of E and D
Additional Solved Problems
Summary
Review Questions
Problems
Multiple-choice Questions vii
3. Electric Fields in Conductors and Dielectrics
3.1 Introduction
3.2 Conductors
3.3 Behaviour of Conductors in an Electric Field
3.4 Electric Current (I)
3.5 Current Density (J)
3.6 Ohm’s Law and Conductivity
3.7 Relationship between J and rv
3.8 Point Form of Ohm’s Law (Relationship between J and E)
3.9 Dielectric Materials
3.10 Polarization
3.11 Electric Displacement Vector in Dielectrics
3.12 Continuity Equation
3.13 Relaxation Time (Tr)
3.14 Resistance and Power
3.15 Boundary Conditions
3.16 Poisson’s and Laplace’s Equations
3.17 Uniqueness Theorem
3.18 Electric Field between Two Concentric Conducting Spheres Using
Laplace’s Equation
3.19 Electric Field due to Coaxial Cable Using Laplace’s Equation
3.20 Electric Field due to Semi Infinite Conducting Planes
3.21 Electric Field due to Two Axial Conducting Cones
3.22 Capacitance
3.23 Capacitance between Two Concentric Spheres
3.24 Capacitance of a Coaxial Cable
3.25 Capacitance of Two Parallel Wires (Single-Phase Transmission Line)
3.26 Energy Stored in a Capacitor
3.27 Energy Stored in a Coaxial Cable
Additional Solved Problems
Summary
Review Questions
Problems
Multiple-choice Questions
4. Magnetostatics
4.1 Introduction
4.2 Magnetic Field due to a Current-Carrying Conductor
4.3 Magnetic Flux and Flux Density
4.4 Biot–Savart’s Law
4.5 Biot–Savart’s Law for Distributed Currents
4.6 Oersted’s Experiment
4.7 Magnetic Field Intensity due to an Infinitely Long Conductor
4.8 Magnetic Field Intensity due to a Finite Length Conductor
4.9 Magnetic Field Intensity along the Axis of a Circular Loop
4.10 Magnetic Field Intensity at the Centre of an Equilateral Triangle Formed by a Wire of Length L
4.11 Magnetic Field Intensity (H) at the Centre of a Square Formed by a Current-Carrying Wire of Length L
4.12 Magnetic Field Intensity due to a Regular Polygon
4.13 Magnetic Field Intensity due to a Solenoid
4.14 Maxwell’s Equation for Magnetic Flux Density
4.15 Ampere’s Circuital Law or Ampere’s Work Law
4.16 Magnetic Field Intensity due to a Solid Conductor
4.17 Magnetic Field Intensity due to a Coaxial Cable
4.18 Magnetic Field Intensity due to an Infinite Sheet of Current
4.19 Magnetic Field Intensity at Any Point in between Two Infinite Parallel Surface Current Sheets
4.20 Differential or Point Form of Ampere’s Circuital Law (Maxwell’s Third Equation)
4.21 Stokes’ Theorem
4.23 Point Form of Magnetic Flux Density
4.24 Magnetic Field Intensity due to a Solenoid using Ampere’s Circuital Law
4.25 Magnetic Field Intensity due to a Toroid using Ampere’s Circuital Law
Additional Solved Problems
Summary
Review Questions
Problems
Multiple-choice Questions
5. Magnetic Force and Inductance
5.1 Introduction
5.2 Scalar Magnetic Potential (Vm)
5.3 Magnetic Potential at the Centre of a Square Loop
5.4 Vector Magnetic Potential (A)
5.5 Vector Magnetic Potential in the Field due to an Infinite Length Conductor
5.6 Vector Magnetic Potential in the Field due to Finite Length Conductor
5.7 Force and Torque on a Moving Charge
5.8 Force on a Differential Current Element
5.9 Ampere’s Force Law: Force Between Two Current Elements
5.10 Force between Two Straight, Infinitely Long Parallel Current Carrying Conductors
5.11 Magnetic Torque due to a Rectangular Differential Current Loop in a Magnetic Field
5.12 Magnetic Dipole and Dipole Moment
5.13 Boundary Conditions for Magnetic Field
5.14 Inductor and Inductance
5.15 Mutual Inductance
5.16 Neumann’s Formula for Mutual Inductance
5.17 Mutual Inductance between Two Solenoids
5.18 Magnetic Energy
5.19 Energy Density Stored in the Magnetic Field
5.20 Energy Stored due to Mutual Inductance
5.21 Magnetic Circuits
5.22 Magnetic Materials
5.23 Characteristics of Magnetic Materials
Additional Solved Problems
Summary
Review Questions
Problems
Multiple-choice Questions
6. Time-Varying Fields
6.1 Introduction
6.2 Faraday’s Law
6.3 Induced EMF in an AC Generator
6.4 Induced EMF in a Coil
6.5 Equation of Continuity for Time-Varying Fields
6.6 Modified Ampere’s Circuital Law for Time-Varying Fields
6.7 Displacement Current
6.8 Ratio between Conduction Current Density and Displacement Current Density
6.9 Conduction, Convection and Displacement Currents
6.10 Maxwell’s Equations for Static Fields
6.11 Maxwell’s Equation for Sinusoidal (Harmonic) Time-Varying Fields
6.12 Boundary Conditions
Additional Solved Problems
Summary
Review Questions
Problems
Multiple-choice Questions
7. Electromagnetic Waves
7.1 Introduction
7.2 Wave Equations in a Homogeneous Medium
7.2.1 Wave Equations for a Perfect Dielectric (Free Space)
7.2.2 Wave Equations for a Conducting Medium
7.3 Time Harmonic Wave Equations (Phasor Notation)
7.4 Uniform Plan Wave Propagation
7.5 Solution for the Uniform Plane Wave Equation
7.6 Characteristic Impedance
7.7 Wave Propagation in a Conducting Medium
7.8 Characteristic Impedance in a Lossy Dielectric or Conducting Medium
7.9 Wave Propagation in Perfect Dielectric Medium
7.10 Expressions for a and b for a Conducting Medium
7.11 Wave Propagation in Good Conductors
7.12 Wave Propagation in Good Dielectrics
7.13 Depth of Penetration (Skin Depth d )
7.14 Polarization of a Uniform Plane Wave
7.14.1 Linear Polarization
7.14.2 Circular Polarization
7.14.3 Elliptical Polarization
7.15 Direction Cosines of a Vector Field
Additional Solved Problems
Summary
Review Questions
Exercise Problems
Multiple-choice Questions
8. Electromagnetic Wave Characteristics
8.1 Introduction
8.2 Reflection and Refraction of a Uniform Plane Wave
8.3 Reflection by a Perfect Conductor with Normal Incidence
8.4 Reflection by a Perfect Dielectric—Normal Incidence
8.5 Reflection of a Plane Wave—Oblique Incidence
8.6 Reflection of a Horizontally Polarized Wave by a Perfect Conductor—Oblique Incidence
8.7 Reflection of a Vertically Polarized Wave by a Perfect Conductor—Oblique Incidence
8.8 Reflection by a Dielectric or Perfect Insulator—Oblique Incidence
8.9 Brewster Angle
8.10 Total Internal Reflection
8.11 Surface Impedance
8.12 Surface Resistance and Surface Reactance
8.13 Poynting Vector and Poynting Theorem
8.14 Poynting Theorem
8.15 Power Loss in a Plane Conductor
Additional Solved Problems
Summary
Review Questions
Problems
Multiple-choice Questions
9. Transmission Lines - I
9.1 Introduction
9.2 Types of Transmission Lines
9.2.1 Transmission Line Parameters
9.3 Transmission Line Equations
9.4 Infinite Length Line
9.5 Transmission Line Terminated with Characteristic Impedance Z0
9.6 Derivation of Attenuation and Phase Shift Constants
9.7 Velocity of Propagation and Group Velocity
9.8 Relationship between Group Velocity and Phase Velocity
9.9 Lossless Transmission Line
9.10 Distortionless Transmission Line
9.11 High Frequency Transmission Line
9.12 Telephone Cable
9.13 Condition for Minimum Attenuation
9.14 Line Distortion
9.15 Conditions to Achieve Minimum Attenuation
9.16 Loaded Line
Additional Solved Problems
Summary
Review Questions
Problems
Multiple-choice Questions
10. Transmission Lines - II
10.1 Introduction
10.2 Standing Waves on a Transmission Line
10.3 Open and Short-Circuited Lines
10.4 Input Impedance of Open and Short-Circuited Lines
10.5 Transmission Line with Load Impedance
10.6 Voltage and Current Distributions on a Lossless Line
10.7 Reflection and Reflection Coefficients
10.8 Standing Wave Ratio
10.9 Input Impedance in Terms of Reflection Coefficient
10.10 Location of Voltage Maxima and Minima
10.11 Impedance Transformation
10.12 Input Impedance of Lossless SC and OC Transmission Lines
10.13 UHF Lines as Circuit Elements
10.14 Stub Matching
10.15 Single Stub Matching
10.16 Double Stub Matching
10.17 Smith Chart
10.18 Properties of the Smith Chart
10.19 Applications of the Smith Chart
10.20 Single Stub Matching Using Smith Chart
10.21 Double Stub Matching Using Smith Chart
Additional Solved Problems
Problems Using Smith Chart
Summary
Review Questions
Problems
Multiple-choice Questions
11. Guided Waves
11.1 Introduction
11.2 Waves between Parallel Planes
11.3 Transverse Electric Waves
11.4 Transverse Magnetic Waves
11.5 Characteristics of TE and TM Waves
11.6 Velocities of Wave Propagation
11.7 Transverse Electromagnetic Waves (TEM Waves)
11.8 Attenuation of Guided Waves
11.9 Wave Impedances
11.10 Relationship between Wave Impedance and Cutoff Frequency
11.11 Fields and Current Flow within the Conductor
11.12 Attenuation of Wave Modes
Additional Problems
Summary
Review Questions
Problems
Multiple-choice Questions
Appendix-A
Appendix-B
Index
